Module No.

USB-PRI-720P V44

Module Size

25mm × 24mm × 11.8mm±0.2MM

Temperature (Operation)

-30°C to 70°C

Temperature (Stable Image)

0°C to 50°C

Assembly technique

SMT (ROSH)

Focus

Fixed

Object distance

30CM-infinity

Resolution

600LW/PH (Center)

PCB printing ink

Black

interface

USB 2.0

Power suuply

USB bus power

supply voltage

DC 5V±5%

Maximum Power consumption

640 mW

Operating system request

Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc

Sensor

OV9726 (1/6.5” )

Seneor Package

CSP,Bare Die

Maximum resolution

1280*800

Sensitivity

1300mV /（lux-sec）

Pixel Size

1.75µm x 1.75µm

Maximum Image Transfer Rate

MJPEG 320x240 30FPS / YUY2 320x240 30FPS MJPEG 640x360 30FPS / YUY2 640x360 30FPS MJPEG 640x480 30FPS / YUY2 640x480 30FPS MJPEG 960x720 30FPS / YUY2 960x720 30FPS MJPEG 1280x720 30FPS / YUY2 1280x720 10FPS MJPEG 1280x800 30FPS / YUY2 1280x800 10FPS

S/N Ratio

36 db

Max Dynamic Range

70 db

Shutter type

Electronic rolling shutter

AGC/AEC/Whiter balance

Auto

Output Formats

YUY2/MJPEG

Microphone

NO

Lens Construction

3P

F/No

2.8

EFL

3.0 mm

FOV

42°

TV Distortion

<1.0%

Relative Illumination (Sensor)

70%

IR Filter

650±10nm

Module Package

Anti-electrostatic tray

Certifications

FCC/CE/ROSH
